Direct Gas-Fired Heater, ETL Listed, for use in Tempering Make-up air. 2000 CFM. Includes a Filtered Intake Hood, Discharge Temperature Controls, and a Safety Disconnect Switch (MH-A1-D.500-15D)
Designed to deliver tempered make-up air for installations requiring frequent air changes. Units are designed for natural and propane gas applications, for outdoor installation.
Supply Fan handles 2000 CFM @ 0.500" wc ESP, Fan runs at 2079 RPM. Supply Motor: 2.0 HP, 3 Phase, 208 V, 60Hz, 6.1 FLA, ODP, Premium (E-Plus3) Eff.
Housing constructed of heavy duty G90 galvanized steel. Forward curved centrifugal blower wheel. Vibration isolation. Adjustable motor pulley.
Includes a Motorized Back Draft Damper, Filtered Intake, Low Fire Start, and Gas Pressure Gauges.
As all fans are custom built, no returns or exchanges are accepted. Horizontal discharge units are available upon request. Roof curb is included.
