5' Long Commercial Kitchen Restaurant Duty Exhaust Hood, Wall Canopy Stainless Steel Exhaust Hood W/Baffle Hood Filters & High Temperature Light Fixtures (Exhaust Fan & Fire Suppression Not Included)
-60” Long x 48” Deep x 24” High Stainless Steel Exhaust-Only Wall Canopy Hood with Built-in 3" Back Standoff and a Factory Installed Round Exhaust Riser. Meets all code requirements in North America.
-Hood has a 600 degree temperature rating which can accommodate medium to heavy duty cooking equipment such as ranges, griddles, fryers, and ovens.
-Constructed of 430 stainless steel where exposed. ETL listed to US and Canadian safety standards. Complies with UL710. Listed and built in accordance with NFPA 96,
-Includes stainless steel grease baffle filters with handles, pre-wired high temperature light fixtures, and a grease cup.
-Manufactured in the USA. Technical support available upon purchase. As all hoods are custom built, no returns or exchanges are accepted. Exhaust fan and fire suppression system not included.
-60” Long x 48” Deep x 24” High Stainless Steel Exhaust-Only Wall Canopy Hood with Built-in 3" Back Standoff and a Factory Installed Round Exhaust Riser. Meets all code requirements in North America.
-Hood has a 600 degree temperature rating which can accommodate medium to heavy duty cooking equipment such as ranges, griddles, fryers, and ovens.
-Constructed of 430 stainless steel where exposed. ETL listed to US and Canadian safety standards. Complies with UL710. Listed and built in accordance with NFPA 96,
-Includes stainless steel grease baffle filters with handles, pre-wired high temperature light fixtures, and a grease cup.
-Manufactured in the USA. Technical support available upon purchase. As all hoods are custom built, no returns or exchanges are accepted. Exhaust fan and fire suppression system not included.
-60” Long x 48” Deep x 24” High Stainless Steel Exhaust-Only Wall Canopy Hood with Built-in 3" Back Standoff and a Factory Installed Round Exhaust Riser. Meets all code requirements in North America.
-Hood has a 600 degree temperature rating which can accommodate medium to heavy duty cooking equipment such as ranges, griddles, fryers, and ovens.
-Constructed of 430 stainless steel where exposed. ETL listed to US and Canadian safety standards. Complies with UL710. Listed and built in accordance with NFPA 96,
-Includes stainless steel grease baffle filters with handles, pre-wired high temperature light fixtures, and a grease cup.
-Manufactured in the USA. Technical support available upon purchase. As all hoods are custom built, no returns or exchanges are accepted. Exhaust fan and fire suppression system not included.
HOOD ADVANTAGES
Exhaust Flow Rates: Superior exhaust flow rates. A 5' Hood can operate at 150 CFM/ft or 750 total CFM for 450 degree appliances or 200 CFM/ft or 1000 total CFM for 600 degree appliances. Available in single, end-to-end, or back-to-back configurations.
ETL Listed: ETL Listed for use over 450°F, 600°F and 700°F cooking surface temperatures, which provides flexibility in designing kitchen ventilation systems. ETL Listed to US and Canadian safety standards, ETL Sanitation Listed and built in accordance with NFPA 96.
Capture and Containment: Insulated, double-wall rigid front has aerodynamic design that reduces radiant heat into kitchen, prevents condensation and provides exceptional capture and containment of cooking vapors. This is accomplished with the mechanical baffle on the front of the hood's capture area and the "C-shaped" design of the hood's capture area. Mechanical baffle provides a built-in wiring chase for optimal positioning of electrical controls and outlets on the front face of the hood without penetrating capture area or requiring external chase way.
Convenient Design: Factory pre-wired lighting to illuminate the cooking surface is accessible from the bottom of the hood. Fitted with UL Listed, pre-wired, incandescent light fixtures and tempered glass globes to hold up to a standard 100 watt bulb. Pre-punched hanging angles on each end of hood and additional set provided for hoods longer than 12'.
Construction: Polished stainless steel on the interior and exterior of the front enhance aesthetics. Fully welded and polished front corners. Fabricated from Type 430 stainless steel.
Channels: Hood comes standard with structural channels on top and wrapper channels on the bottom.
Reduced Weight: Rigid single wall end panels reduce weight.
Grease Extraction: All hoods come standard with stainless steel baffle filters and a deep grease trough which allows for easy cleaning. High efficiency filters are optional. Grease drain system with removable 1/2 pint cup for easy cleaning. Standard filter stops eliminate gaps between filters.
